Terrain Pilot X5

Get fast, hassle-free excavator guidance without running complex wiring harnesses across your machine. The Terrain Pilot X5 is a streamlined, all-wireless 3D guidance system designed for owner-operators and contractors who want quick deployment, core grading accuracy, and simple operation.

Featuring a direct stick-mounted wireless RTK receiver and a solar-assisted wireless tilt sensor, the X5 connects via Bluetooth/Wi-Fi to provide real-time bucket positioning and CAD plan viewing directly inside your cab.

Key Features & Benefits

• 100% Wireless Installation: No complicated machine wiring or welding. Transfer easily between machines or install within minutes.
• Bluetooth & Wi-Fi Connectivity: Seamless cable-free communication between the cab display and excavator sensors.
• All-Day Battery Life: The stick-mounted RTK unit provides up to 18 hours of continuous operation, paired with a solar-powered wireless sensor.
• Core 3D Guidance & CAD Viewing: Import and view site CAD drawings, check cut/fill depths, and maintain grade right from the cab.
• Cost-Effective Precision: Delivers essential GNSS grade guidance without the complexity or expense of permanent dual-antenna installations.

System Specifications

Ideal Applications

• Trenching & Basements: Maintain exact elevations and avoid over-digging.
• Site Leveling & Pads: Dig flat pads and basic gradients quickly with in-cab visual references.
• Contractors on the Move: Easily transfer the entire kit between machines on different job sites.
